| SPECIFICATIONS | TC-816A |
| Size of Hot Plate | 125 x 220 mm |
| Diameter of Rubber Roller | ---- |
| Length of Rubber Roller | ---- |
| Work Table Size | 200 x 200 mm |
| Max. Pressure | 200 Kg |
| Max. Head Stroke | 60 mm |
| Max. Table Stroke | 250 mm |
| Max. Opening (Flat) | 160 mm |
| Max. Opening (Cylindrical) | 70 mm |
| Voltage Supply | 220 V |
| Heater Capacity | 1,000 W |
| Foil Controller | Motor Drive |
| Thermo Controller | 0 - 400oC |
| Net Weight | 153 Kg |
| Gross Weight | 195 Kg |
| Dimension (L x W x H) | 640 x 580 x 1060 mm |
| Standard Tubes come with Machine | ---- |
 |
